[ GEFORCE ]
Graphics Cards
GeForce GTX 1080 Ti
Overall Score
32/100
Key Technical Specifications
Graphics (GPU)
Pascal
[ EXPERT VERDICT · SUMMARY ]
GeForce GTX 1080 Ti is an engineering-tested graphics cards achieving an overall rating of 32/100. It is positioned for balanced everyday compute and power efficiency.
Benchmark Performance Scores
Normalized 0–100 Scale
Efficiency
Rating: Poor
20/100
Gaming
Rating: Poor
31/100
Detailed Technical Specifications
3D Mark
| Specification | Value |
|---|---|
| Fire Strike | 29329 |
| Night Raid | 95847 |
| Port Royal | 2266 |
| Solar Bay | 26263 |
| Time Spy | 9981 |
| Wild Life Extreme | 20170 |
API
| Specification | Value |
|---|---|
| CUDA | 6.1 |
| DLSS | No |
| DirectX | 12 |
| DisplayPort | 1.4a |
| OpenCL | 3.0 |
| OpenGL | 4.6 |
| Ray Tracing | No |
| Vulkan | 1.3 |
Games
| Specification | Value |
|---|---|
| 1080p High | 109 |
| 1080p Ultra | 88 |
| 1440p Ultra | 65 |
| 4K Ultra | 35 |
| CoD: Modern Warfare III | 91795639 |
| Counter-Strike 2 | 19914610651 |
| Cyberpunk 2077 | 77704218 |
| Far Cry 6 | 102907238 |
| Forza Horizon 5 | 119766542 |
| Ghost of Tsushima | 69544225 |
| Hogwarts Legacy | 75594623 |
| Margin of Error | Low |
| Shadow of the Tomb Raider | 1181097840 |
| The Witcher 3 | 1341108142 |
GeekBench 6 ML
| Specification | Value |
|---|---|
| Backend | DirectML |
| Depth Estimation (Q) | 20303 |
| Face Detection (HP) | 13001 |
| Framework | ONNX |
| Image Classification (SP) | 3882 |
| Image Segmentation (HP) | 7960 |
| Image Super Resolution (Q) | 14401 |
| Machine Translation (HP) | 3577 |
| Object Detection (SP) | 4757 |
| Pose Estimation (Q) | 72329 |
| Style Transfer (SP) | 164740 |
| Text Classification (SP) | 1910 |
GeekBench 6 OpenCL
| Specification | Value |
|---|---|
| API | OpenCL |
| Background Blur | 200.9 img/sec |
| Edge Detection | 5.57 Gpixels/sec |
| Face Detection | 88.6 img/sec |
| Feature Matching | 0.33 Gpixels/sec |
| Gaussian Blur | 5.79 Gpixels/sec |
| Horizon Detection | 3.55 Gpixels/sec |
| Particle Physics | 6315.6 FPS |
| Stereo Matching | 265.6 Gpixels/sec |
General
| Specification | Value |
|---|---|
| AMD Equivalent | -Radeon RX 5700 XT |
| Architecture | Pascal |
| Build | Discrete |
| Case | Desktop |
| GPU Codename | GP102 |
| Launch price (MSRP) | $699 |
| Purpose | Gaming |
| Recommended CPU | -Intel Core i7 7700Kor above |
| Released | March 10, 2017 |
| Segment | High-end |
| Successor | -GeForce RTX 3080 Ti |
| Vendor | Nvidia |
Graphics Processing Unit
| Specification | Value |
|---|---|
| Base Clock | 1481 MHz |
| Boost Clock | 1582 MHz |
| Compute Units (Pipelines) | 28 |
| Instructions Per Cycle | 2 IPC |
| L1 Cache | 48KB per cluster |
| L2 Cache | 2816KB shared |
| Ray-tracing Cores | No |
| Render Output Units (ROPs) | 88 |
| Shading Units | 3584 |
| Tensor Cores | No |
| Texture Mapping Units (TMUs) | 224 |
Memory
| Specification | Value |
|---|---|
| Bus | 352-bit |
| ECC | No |
| Effective Memory Speed | 11000 Mbps |
| Memory Clock | 1376 MHz |
| Memory Size | 11 GB |
| Memory Type | GDDR5X |
Passmark Graphics
| Specification | Value |
|---|---|
| DirectX 11 | 151 FPS |
| DirectX 12 | 66 FPS |
| G2D Mark | 941 |
| GPU Compute | 9585 Ops/s |
Physical
| Specification | Value |
|---|---|
| Die Size | 471 mm² |
| Fabrication Process | 16 nm |
| Interface | PCIe 3.0 x16 |
| Manufacturing | TSMC |
| TGP | 250 W |
| Transistor Count | 11 billion |
| Transistor Density | 23.35 MTr/mm² |
Raw Performance
| Specification | Value |
|---|---|
| Pixel Fill Rate | 139 GPixel/s |
| Texture Fill Rate | 354 GTexel/s |
Strengths & Limitations
Key Advantages
- Comprehensive positive benchmark metrics recorded.
Key Considerations
- No major hardware limitations flagged during benchmark run.
Direct Competitors & Alternatives
NVIDIA
Nvidia RTX Pro 6000 Blackwell
98/100
Compare →
GEFORCE
GeForce RTX 5090
96/100
Compare →
GEFORCE
GeForce RTX 4090
89/100
Compare →
AMD
AMD Radeon RX 7900 XTX
85/100
Compare →
Methodology, Provenance & Verification
Score version 2026.1 · Data verified 2026-08-26 · Source: official manufacturer datasheets and standardized reproducible benchmark suites (Geekbench 6, Cinebench R24, 3DMark).
